Description
Weight
Operating mass (incl. ROPS): 11,000 lb
Operating mass (incl. Cab): 12,150 lb
Module mass (front/rear): 4,900 lb / 6,100 lb
Max. operating mass: 11,800 lb
Compaction
Static linear load: 73 lb/in
Compaction width: 54 in
Drum type: Padfoot with Blade
Number of pads: 72
Pad area: 8.2 in²
Pad height: 3 in
Traction
Speed range: 0–4 mph
Tire size (10 ply): 12.5–20
Max. theoretical gradeability: 52%
Vertical oscillation: ±9°
Steering angle: ±33°
Engine / Drive
Manufacturer / Model: Yanmar 4TNV98CT-PDCE (Stage V / Tier 4f)
Type: Water-cooled turbo Diesel
Rated power, SAE J1995: 72 hp (54 kW) @ 2,250 rpm
Fuel tank capacity: 31 gal
Hydraulic System
Driving: Axial piston pump with variable displacement
Vibration: Gear pump/motor with constant displacement
Steering: Gear pump with constant displacement
Brakes
Service brake: Hydrostatic in forward and reverse lever
Parking / Emergency brake: Fail-safe multidisc brake in rear axle and front drum motor
