Description
Masses
Operating mass (incl. ROPS): 29,800 lb
Operating mass (incl. Cab): 30,200 lb
Module mass (front/rear): 19,400 lb / 10,800 lb
Max. operating mass: 33,500 lb
Compaction
Static linear load: 229.56 lb/in
Compaction width: 84 in
Drum type: Smooth
Nominal amplitude (high/low): 2.0 mm / 0.8 mm
Vibration frequency (high/low amplitude, SEISMIC manual mode): 1,800 vpm / 1,800 vpm
Centrifugal force (high/low amplitude): 60,700 lb / 26,980 lb
Traction
Speed range: 2 – 7 mph
Tire size (12 ply): 23.1 x 26 AW
Max. theoretical gradeability: 55%
Vertical oscillation: ±9°
Steering angle: ±38°
Engine / Drive
Engine: Cummins B4.5 (Stage V / T4final) – 149 kW (200 hp) @ 2,200 rpm
Type: Water-cooled turbo Diesel
Fuel tank capacity: 67 gal
DEF tank capacity: 8 gal
Hydraulic System
Driving: Hydrostatic
Vibration: Hydrostatic
Steering: Hydrostatic
Brakes
Service brake: Hydrostatic in forward and reverse lever
Parking / Emergency brake: Failsafe multidisc brake in drum gearbox and rear axle
