Description
Masses
Operating mass (incl. ROPS): 35,280 lb
Operating mass (incl. Cab): 35,700 lb
Module mass (front/rear): 23,600 lb / 12,100 lb
Max. operating mass: 41,200 lb
Compaction
Static linear load: 280 lb/in
Compaction width: 84 in
Drum type: Smooth
Nominal amplitude (high/low): 0.083 in / 0.031 in
Vibration frequency (high/low amplitude, SEISMIC manual mode): 1,740 vpm / 1,800 vpm
Centrifugal force (high/low amplitude): 74,190 lb / 31,470 lb
Traction
Speed range: 2 – 7 mph
Tire size (12 ply): 23.1 x 26 AW
Max. theoretical gradeability: 49%
Vertical oscillation: ±9°
Steering angle: ±38°
Engine / Drive
Engine: Cummins B4.5 (Stage V / T4 Final) – 149 kW (200 hp) @ 2,200 rpm
Type: Water-cooled Turbo Diesel
Fuel tank capacity: 67 gal
DEF tank capacity: 8 gal
Hydraulic System
Driving: Hydrostatic
Vibration: Hydrostatic
Steering: Hydrostatic
Brakes
Service brake: Hydrostatic in forward and reverse lever
Parking / Emergency brake: Failsafe multidisc brake in drum gearbox and rear axle
