Dynapac CC1300C VI Combi Roller

Dynapac CC1300C VI Combi Roller

The Dynapac CC1300C VI is a medium-class asphalt roller with a drum width of 51 inches. This machine features a combination configuration, with a steel drum at the front and four wide tires at the rear, providing excellent traction, stability, and compaction versatility. Powered by a reliable Kubota diesel engine, and combined with its large drum diameter and hydrostatic drive with series-connected radial piston motors, the CC1300C VI delivers excellent accessibility and hill-climbing capability of up to 41%.

It is ideal for medium-scale compaction projects such as pavements, streets, cycle paths, and parking areas. The Dynapac CC1300C VI comes with vibration on the front drum, ensuring efficient and uniform compaction, while the rear tires help achieve a smooth, finished surface.

Request a Quote
SKU: CC1300C VI Category: Tags: , , Brand:

Description

Masses
Max. operating mass: 10,100 lbs
Operating mass (incl. ROPS): 8,200 lbs
Module mass (front/rear): 4,100 lbs / 4,100 lbs

Traction
Speed range: 6 mph
Vertical oscillation: ±10°
Max. theoretical gradeability: 41%

Engine
Manufacturer: Kubota
Model : V2403-CR E4B (T4)
Type: Water cooled diesel engine
Rated power, SAE J1995: 50 hp (37 kW) @ 2,700 rpm
Fuel tank capacity:16 gal

Hydraulic System
Driving: Axial piston pump with variable displacement. Radial piston motors with constant displacement.
Vibration: Gear pump/motors with constant displacement.
Steering: Gear pump with constant displacement.
Service Brake: Hydrostatic in forward and reverse lever.
Parking / Emergency Brake: Failsafe multidisc brake on drum and wheels.

Configuration
Front: Steel drum with vibration
Rear: Four wide tires for traction and smooth finishing

Technical Specs

Class - ton

Drum/Rolling Width - in

Drum/Rolling Width - mm

Oper. Weight - lb

Oper. Weight - kg

Vibration

Engine Type

Engine HP

Length

Height
