Description
Masses
Max. operating mass: 24,300 lbs
Operating mass (incl. ROPS): 20,700 lbs
Module mass (front/rear): 11,000 lbs / 9,700 lbs
Traction
Speed range: 0–7.5 mph
Vertical oscillation: ±7°
Max. theoretical gradeability: 41%
Engine
Manufacturer: Cummins
Model: F3.8 V
Type: Water-cooled turbo diesel
Rated power, SAE J1995: 97 kW (130 hp) @ 2,200 rpm
Fuel tank capacity: 48 gal
DEF tank capacity: 4 gal
Hydraulic System
Driving: Axial piston pump with variable displacement, radial piston motors (2) with variable displacement
Vibration: Axial piston pumps (2) with variable displacement, axial piston motors (2) with constant displacement
Steering: Gear pump with constant displacement
Service: Hydrostatic in forward and reverse lever
Parking/Emergency: Failsafe multidisc brake in both drums
Compaction CE
Centrifugal force (high/low amplitude): 23,820 lb / 15,280 lb
Vibration frequency (high/low amplitude): 2,640 vpm / 3,480 vpm
