Description
Masses
Operating mass (incl. ROPS): 21,200 lb
Operating mass (incl. Cab): 21,826 lb
Mass with water ballast: 28,660 lb
Mass with wet sand ballast: 35,935 lb
Mass with max. ballast: 61,729 lb
Traction
Transmission: Hydrostatic, direct-drive motors at rear tyres
Speed (low): 4.3 mph
Speed (high): 12.4 mph
Max. theoretical gradeability: 27%
Engine
Manufacturer: Cummins
Model (Tier 4F/Stage V): F 3.8
Rated power, SAE J1995: 134 hp (101 kW) @ 2,200 rpm
Type: Water-cooled turbo diesel
Fuel tank capacity: 55.5 gal
DEF tank capacity: 6 gal
Hydraulic System
Driving: Axial piston pump with variable displacement; 2 variable-displacement motors
Steering: Hydrostatic
Service brake: Dual multidisc brakes on rear wheels
Parking / Emergency brake: Failsafe multidisc brakes in both gearboxes
