Description
Operator’s Controls
High deck/low deck configuration
Dash panel is movable from left to right and contains all machine controls
Pivot steer and posi-trac
Equipped with auger and conveyor bypass
Color graphic control screen with digital readouts. Review and monitor system vitals including: oil pressure, hour meter, fuel gauge, volt meter, water temp, tachometer, hydraulic oil temp, engine diagnostics
Dimensions
Length: 16’ 6”
Width: 8’ 6” transport
10’ 7” hopper wings down
Height: 7’ 8”
Total Weight (with screed): 17,550 lbs
Engine
Kubota turbocharged diesel
Tier 4 Final – 74hp (55 kw) @ 2,200 RPM
Capacities
Fuel: 36 gallons
Hydraulic: 36 gallons
Washdown tank: 7 gallons
Paving Widths
Variable paving widths up to 15’
