MultiQuip MRH800GS Tandem Drum Rollers

Multiquip’s rugged walk-behind tandem rollers all feature advanced engineering and design satisfying the needs of the most demanding contractors.
– Hour/tachometer measures runtime and engine rpm
– Hydrostatic drive eliminates drive belts and adjustments
– Infinite variable speed control gives the operator full control with forward, reverse speeds
– External mounted vibrator assembly for easy maintenance access
– Deadman safety control stops roller when the operator takes hands off the control levers
– Large rubber shock mounts minimize drum vibration transfer to engine, hydraulic components
– Guide handle folds up 90 degrees for easy transport and storage
– Narrow profile design for less than 1 inch (25 mm) side clearance
– Dual sprinkler controls wet drum individually
– Single access maintenance cover for easy access to all hydraulic components
– Permanently lubricated bearings are maintenance free
– Built-in tie-downs on all four corners secure the roller during transport
*Battery not included

SKU: MRH800GS Category: Tags: , Brand:

Description

Unit Specifications
Compaction Force: 5300 lb / 23.57 kN
Frequency: 3300 VPM / 55.3 Hz
Travel Speed: 0-2 mph / 0-3 kph
Water Tank Capacity: 10.6 gal / 40.12 L

Drum Specifications
Front Drum Width: 25.6 in / 650 mm
Rear Drum Width: 25.6 in / 650 mm

Dimensions & Weights
Overall Length: 105 in / 2667 mm
Overall Width: 27.2 in / 691 mm
Overall Height: 41.7 in / 1059 mm
Operating Weight: 1530 lb / 694 kg
