Description
Weight
Operating mass (incl. ROPS): 14,350 lb
Operating mass (incl. Cab): 14,900 lb
Module mass (front/rear): 7,500 lb / 6,850 lb
Max. operating mass: 15,500 lb
COMPACTION
Static linear load: 112 lb/in
Compaction width: 66 in
Drum type: Padfoot
Number of pads: 132
Pad area: 13 in²
Pad height: 3 in
Traction
Speed range: 0–6.2 mph
Tire size (16 ply): 400/60-22.5 flotation
Max. theoretical gradeability: 50%
Vertical oscillation: ±9°
Steering angle: ±33°
Engine / Drive
Manufacturer / Model: Kubota V3307 CR-TE4 (Stage IIIB/T4f)
Type: Water-cooled turbo Diesel
Rated power, SAE J1995: 75 hp (55 kW) @ 2,200 rpm
Fuel tank capacity: 31 gal
Hydraulic System
Driving: Hydrostatic with a traction pump supplying two parallel-connected motors, one on rear axle and one on drum
Vibration: Hydrostatic with a vibration pump supplying a motor connected to the eccentric axle generating the vibrations
Steering: Mechanical-hydraulic with steering valve supplying the steering cylinder; steering angle proportional to steering wheel
Brakes
Service brake: Hydrostatic in forward and reverse lever
Parking / Emergency brake: Failsafe multidisc brake in rear axle and front drum motor
