Description
Masses
Max. operating mass: 10,600 lbs
Operating mass (incl. ROPS): 8,600 lbs
Module mass (front/rear): 4,100 lbs / 4,500 lbs
Traction
Speed range: 0–5.6 mph
Vertical oscillation: ±10°
Max. theoretical gradeability: 42%
Engine
Manufacturer: Kubota
Model: V2403-CR E4B (T4)
Type: Water-cooled diesel engine
Rated power, SAE J1995: 50 hp (37 kW) @ 2,700 rpm
Fuel tank capacity: 16 gal
Hydraulic system
Driving: Axial piston pump with variable displacement, 2 radial piston motors with constant displacement
Vibration: Gear pump/motors with constant displacement
Steering: Gear pump with constant displacement
Service brake: Hydrostatic in forward and reverse lever
Parking/Emergency brake: Failsafe multidisc brake in both drums
