Description
Masses
Max. operating mass: 19,500 lbs
Operating mass (incl. ROPS): 17,600 lbs
Operating mass (incl. Cab): 18,200 lbs
Operating mass (incl. Cab and offset): 18,750 lbs
Module mass (front/rear): 9,000 lbs / 8,600 lbs
Traction
Speed range: 0–7.5 mph
Vertical oscillation: ±6°
Max. theoretical gradeability: 45 %
Engine
Manufacturer / Model: Deutz TCD 3.6 HT T4f
Type: Water-cooled turbo diesel
Rated power, SAE J1995: 74 hp @ 2200 rpm
Fuel tank capacity: 34 gal
Service Brake: Hydrostatic in forward and reverse lever.
Parking / Emergency Brake: Failsafe multidisc brake in both drums.
Compaction CE
Centrifugal force (high/low amplitude): 75 / 40 kN
Vibration frequency (high/low amplitude): 47 Hz / 53 Hz
