Description
Masses
Max. operating mass: 32,800 lbs
Operating mass (incl. ROPS): 26,000 lbs
Module mass (front/rear): 13,000 lbs / 13,000 lbs
Traction
Speed range: 0–7.5 mph
Vertical oscillation: ±7°
Max. theoretical gradeability: 34 %
Engine
Manufacturer: Cummins
Model: QSF 3.8 IV/T4f
Type: Water cooled turbo diesel
Rated power, SAE J1995: 130 hp (97 kW) @ 2,200 rpm
Fuel tank capacity: 48 gal
DEF tank capacity: 4 gal
Hydraulic System
Driving: Axial piston pump with variable displacement. Radial piston motors (2) with variable displacement.
Vibration: Axial piston pumps (2) with variable displacement. Axial piston motors (2) with constant displacement.
Steering: Gear pump with constant displacement.
Service Brake: Hydrostatic in forward and reverse lever.
Parking / Emergency Brake: Failsafe multidisc brake in both drums.
Compaction CE
Centrifugal force (high/low amplitude): 23,820 lb / 15,280 lb
Vibration frequency (high/low amplitude): 2,640 vpm / 3,480 vpm
