Description
Masses
Module mass (front/rear): 23,368 lb / 26,345 lb
Operating mass (incl. Cab and blade): 49,700 lb
Max. operating mass: 49,700 lb
Compaction
Contact area of pads: 31 in²
Height of pads: 7.28 in
Number of pads per drum: 60
Traction
Speed range (forward/back, mph):
• 1st: 2.3
• 2nd: 5.3
• 3rd: 9.1
• 4th: 12.4
Transmission: Power shift Dana 36000, transmission converter integrated, 4 automatic speeds
Vertical oscillation: ±12°
Each drum mounted on 2 tires: 11.00 x 22 – 12 ply
Engine / Drive
Manufacturer/Model: Cummins QSB 6.7, Tier 3 or 4F
Type: Turbo Diesel, water cooled with intercooler
Rated power, SAE J1995: 194 kW (260 hp) @ 2,200 rpm
Fuel tank capacity: 88 gal
Hydraulic System
Driving: Hydrostatic
Service brake: Hydraulic on differential
Parking / Emergency brake: Caliper on the disc
