Description
Operator’s Controls
All control levers are on the left side
Right side levers include left and right drive control, right auger, right screed extension and hopper
Color graphic control screen with digital readouts. Review and monitor system vitals including: oil pressure, hour meter, fuel gauge, volt meter, water temp, tachometer, hydraulic oil temp, engine diagnostics
Dimensions
Length: 9’6”
Width: 8’6” transport
9’ hopper wings down
Height: 7’
Total Weight (with screed): 11,000 lbs
Engine
Kubota turbocharged diesel
Tier 4 Final – 49hp (37kw) @ 2,600 RPM
Capacities
Fuel: 13.5 gallons
Hydraulic: 45 gallons
Washdown tank: 7 gallons
Paving Widths
Variable up to 13’
