Technical Specifications
Operator’s Controls
High deck/low deck configuration
Includes dual electronic steer
All control switches are located in one box that can be slid to each side. Dash panel includes augers, screed extension, cut-offs, hopper wings, conveyors, grade controls, and lights
Color graphic control screen with digital readouts. Review and monitor system vitals including: oil pressure, hour meter, fuel gauge, voltmeter, water temp, tachometer, hydraulic oil temp, engine diagnostics
Dimensions
Length: 15’ 3” | 14’ 3” transport
Width: 8’ 6” transport – 10’ hopper wings down
Height: 6’ 10” high deck
Total Weight: 21,920 lbs.
Engine
Kubota turbocharged diesel,
Tier 4 Final – 125 hp (93 kw)
Capacities
Fuel: 32 gallons
Hydraulic reservoir: 25 gallons
Washdown tank: 7 gallons
DEF tank: 5 gallons
Paving Widths
Machine has variable paving widths up to 15’
Machine has variable paving widths up to 15’ 6″ (with HD Pro Screed)
