Description
Operator’s Controls
All control levers are on the left side
Right side levers include left and right drive control, right auger, right screed extensions
Includes a horn and back-up alarm
Color graphic control screen with digital readouts. Review and monitor system vitals including: oil pressure, hour meter, fuel gauge, voltmeter, water temp, tachometer, hydraulic oil temp, engine diagnostics
Dimensions
Length: 11’
Width: 8’6” transport
10’ hopper wings down
Height: 7’, adjustable to 6’4”
Total Weight (with screed): 13,000 lbs
Engine
Kubota turbocharged diesel
Tier 4 Final – 64 hp (48kw) @ 2,400 rpm
Capacities
Fuel: 13 gallons
Hydraulic: 40 gallons
Washdown tank: 7.5 gallons
Paving Widths
Variable up to 13’
