Description
Technical Specifications
Dimensions (Trailer Configuration)
Dimensions are dependent upon type of truck purchased and options selected.
Engine
Kubota – 24.8 hp (18.5 kW)
Capacities
Fuel: 16 gallon
Tank Dimensions
Length: 64”
Width: 70”
Height: 42”
Asphalt Pump
150 gallons per minute Viking asphalt pump
Heat System
One 300,000 BTU diesel burner
Five pass flue system
Galvanized exhaust stack
Temperature Gauge
0 – 500ºF
Adjustable angle faceplate
Flush Tank
7 gallons
Wireless In-Cab Controls
Color display with readouts for: engine rpm, engine fault status, system faults, engine hours, ground speed, application rate, spray width,
material temperature, material temperature set point, mode selection, asphalt pump current speed, valve status, totals screen
Auto/Manual pump selector
Manual pump speed dial
Engine start/stop
Bar circulate/off/spray switch
Bar section on/off for left wing, left center, right center, right wing
Mode selector: off, spray/bar circulate, tank circulate/hand spray, reverse suction, cleanout, calibration
E-stop
