Description
Operator’s Controls
High deck/low deck configuration
Includes dual electronic steer
Dual, independent adjustable control stations interchangeable in the field
Dash panel includes augers, screed extension, cut-offs, screed, hopper wings, conveyors, grade controls, steering and lights
User-friendly, icon-based CAN Bus controls
Backlit keypad with LED indicator lights
Colored LED, sunlight viewable control screen with digital readouts. Review and monitor system vitals including: RPM, paving speeds, system pressures, screed temperature and generator usage
Dimensions
Length: 16’ 4’
Width: 8’ 6” transport – 10’ hopper wings down
Height: 6’ 8” low deck – 7’ 10” high deck
Total Weight (with screed): 23,450 lbs
Engine
Kubota turbocharged diesel
Tier 4 Final – 127 HP (95 kW)
Remote mounted DOC + DPF + SCR
MURR I/O distributor blocks with LED lighting
Capacities
Fuel: 37 gallons
Hydraulic: 31 gallons
Washdown tank: 7 gallons
DEF tank: 5 gallons
Paving Widths
Machine has variable paving widths up to 15’ 6”
