Description
Technical Specifications
Controller
Plus+1 CAN Bus control and onboard diagnostic system
7″ high-resolution, color graphic display
Controller for automatic application rate control
Automatic valves for cab control of distributor functions
Exclusive enviro-flush system with hydraulic pump speed control
Settings for flow, speed calibration, spraybar width and spray bar on/off control by section
Automatic valves for cab control of distributor functions
Capable of storing up to 12 preset combinations of application rates and flow calibrations for instant retrieval
Selectable readouts include FPM, GPM, total feet sprayed, total gallons sprayed, total square yards sprayed, flow and speed calibration, application rate, tank temperature, hour meter and spraybar width (English and metric units can be selected for the rate controls)
Controller provides accurate applications regardless of changes in speed or spraybar width during operations
Includes radar horn ground speed sensor
Convenient external controls mounted on rear fender
Asphalt Pump
Viking, positive displacement pump
Rotary gear type with built-in relief valve for safety
Asphalt pump driven by low speed high torque fixed displacement hydraulic motor and connected by a flexible coupling
Pump: 400 gallons per minute
Dimensions
Length: Depends on type of truck purchased and options selected
Width: Depends on type of truck purchased and options selected
Height: Depends on type of truck purchased and options selected
Weight: Depends on type of truck purchased and options selected
Capacity
990 gallons to 5,313 gallons**See Spec Sheet for important info
