Description
Dimensions
Length: 15’1″ w/ Trailer hitch down
13′ w/ Trailer hitch up
12’2″ w/o Tow package
Width: 9′ Brush centered
7’7″ Brush fully rotated
Height: 8’ 1′ Beacon flipped down, shipping
8’9″ Beacon flipped up, operating
Wheelbase: 8’5″
Track width: 4’3″
Ground Clearance: 7″
Turning Radius: 10’2″ center front wheel
Turning Circle: 6’6″ inside rear wheel
Total Weight: 3,050 lbs. w/o water (Canopy)
3,175 lbs. w/o water (Cab)
3,650 lbs. w/ water (Canopy)
3,775 lbs. w/ water (Cab)
Engine
Standard: 25 hp max @ 2,300 rpm, Kubota V1505-E4B (Canopy)
Optional: 25 hp max @ 2,300 rpm, Deutz D2.2 (Cab)
Electrical system: 12 volt system, alternator and battery
Fuel reservoir: 8 gallons
Brush Location
Center-Mount Brush Location
Brush
Toggle switch controls
Variable down pressure
Speed: 180 rpm max, variable by engine speed
Drive mechanism consists of direct hydraulic motor
Filler: wafer type. poly, 24″ diameter, 8′ long
Sweep angle: 50°, left or right
